下挖6米150立方每小時處理量挖沙淘金設備詳細清單

挖沙淘金設備,淘金船,沙金設備

流程概述：

原料通過挖斗送入滾筒篩內進行篩選分級為：6mm以下、6-2cm、2cm以上三種規格，其中2CM以上廢料直接通過廢料溜槽排出；

6mm以下細料通過料斗進入一臺自動洗選機中按礦物比重進行初次選別：含金量高的重礦進入一臺80#臥式全自動排礦離心機中進行精選，精料通過排料管排出至料筒中，廢料通過廢料管排出。含金量低的輕礦排入一臺振動溜槽進行收尾后，廢料排出至船尾；

6-2cm粗料通過滾筒篩底部溜槽排入振動溜槽進行回收后，廢料排出至船尾。

Technological process:

The mixture from buckets moved by wheels under and upaward water to trommel screen then separated to 3sizes material:≤6mm,6-2cm,≥2cm,the biggest which useless are directly getting rid to the river.

The material size≤6mm from the auto wash&separating machine to be separated 2 types,the one higher in gold then sending to 80#horizontal auto discharging centrifugal contrator to resparate,the tailings discharge to the box,the one low in gold are sending to shaking chute.

The material 6-2cm go through the screen then also washed to shaking chute to separate,then scrap material are sending out of the dredger.

名稱 Description&name	規格 Specification	數量 Quantity	功率 Power/KW	備注 Remark
浮體Pontoon	單寬1.8米，高0.92米，長23米 Single width:1.8M Height:0.92m Length:23m	1套	-
挖斗式洗沙機 Bucket type gold dredger	主支架高5.6米：16#槽鋼對扣 Main gantry:5.6m Double 16# U steel 水下大臂長16.5米：12#/10#槽鋼 Length of Arms under water:16.5m 12#/10#Usteel 80#挖斗：共60個 Bucket：80#total 60pcs 鏈條：高錳鋼焊接 Chain:high manganese steel 減速機：850# Reducer:850#	1套	37KW-6KW
滾筒篩 Trommel screen	凈篩孔長度3米，內徑1.3米，外徑：1.6米 Trommel screen Length:3m Inner dia.:1.3m Outside Dia.:1.6m 支架：15#方管 Gantry:15#square pipe steel	1套	11
自動洗選機 Auto wahsing separator	60#	1套	2.2
臥式離心機 Horizontal centrifugal contrator	80#全自動排礦離心機 Auto discharging Model 80#	1套	7.5	PLC電腦控制 Controlled by PLC
振動溜槽 Gold shaking chute	1500*4500	1套	3
大臂卷?yè)P(yáng)機	400#減速機Speed Reducer	1臺	11
主錨 Main Anchor	350#減速機Speed Reducer	1臺	3
錨繩卷?yè)P(yáng)機 Winding engine of Anchor line	3KW	4臺	12
水泵 Water pump	7.5KW	1臺	7.5
離心泵 Centrifugal Pump	7.5KW	1臺	7.5
總用量功率	同時用電量101.7KW，工作中用電量：75.7KW(不含照明及其它建議用150KW發電機組) Power during working Period:75.7kw,101.7KW power needed to run(not including lights,we advise to use generator unit of 150kw )
